Crude and HFO Storage Container

Crude Oil & HFO Storage Tank

Information

The High Capacity Crude and HFO Storage Tank provide an innovative and versatile solution for temporary storage needs, from wellhead testing sites to intermediate storage in remote locations. These tanks are designed to store crude and heavy fuel oils (HFOs), meeting industry standards and ensuring optimum safety and protection of both product and user.

To complement our storage tanks, we also offer a range of product-specific ancillary equipment, including level sensing, venting, and blanketing systems, ensuring all your project specifications are met.

ENHANCED STORAGE CAPACITY

With capacities ranging from 180bbl to 415bbl, benefit from storing large but manageable volumes of crude oil and HFO efficiently, ensuring a seamless supply chain and uninterrupted operations.

UNMATCHED SAFETY

Our crude oil and HFO storage tanks feature a double-walled design, meeting standards for safety and environmental protection. With the outer wall also serving as robust protection, these tanks provide an extra layer of defence, preventing any potential leaks or spills from compromising the site safety.

OPTIMAL TEMPERATURE CONTROL

With our specially configured heating systems, you can achieve fast and uniform heating throughout the tank, minimizing heat loss and reducing energy consumption. The strategically placed heating elements ensure efficient heat transfer, preventing any cold spots and guaranteeing consistent product quality.

Key features

180bbl or 415bbl capacity options
Factory-fitted double-layered heating coil for optimal temperature control
Easy product monitoring through the use of convenient flange connections
Double-walled design, alongside corner twist locks, improving strength and durability of the tanks
Simplified installation logistics thanks to the ability to be transported as standard 20ft or 40ft tank containers

Ratings

	180bbl	415bbl
Max GW	35,125kg	75,700kg
Payload	28,825kg	66,000kg
Tare Wt.	<6,300kg	<9,700kg

Measurements

	180bbl	415bbl
Length	6,058mm (20’)	12,192 mm (40’)
Width	2,438mm (8’)	2,438 mm (8’)
Height	2,591mm (8’6”)	2,895 mm (9’6”)
